Wellljets W5500 Continuous Inkjet Printer


Simple Operation  Stable Performance  Low Maintenance

W5500s/W5400s inkjet printer, it is designed with the stable Linux operation software to provide you with a better understanding of how your printer is performing.  It provides content and quality at the highest production speeds. Whether you operate at the extremes of packaging line speed or push the limits on throughput, the W5500s  Hi-Speed printers are designed for your application. it integrates the stable performance, convenient operation wide application and reasonable use cost perfectly to provide you with high-quality service, so that you can easily control and obtain your inkjet needs.

Advantages & Benefits:

Up to 5 lines of print

Variable nozzle size optional based on products

Line speeds up to 1200 ft/min (366m/min)

Wireless connectivity to Windows tablet & Mobile

Simple maintenance with quick disconnect

Start-up/shutdown procedure with auto-flush function to minimize the clogging, and maximum the production lines output.

replacement components

W5500s Features:

Unique high-definition resolution up to 1280*800dpi, easy to operate tablet inspired 10.1”, touch screen display with vivid icon interface

Support all windows fonts, support vector fonts, scalable fonts.

The core board is more efficient, faster processing and more powerful.

Increase the dynamic delivery function of the dot matrix font to meet all printing needs of customers.

Printing Speed W5500s & 5400s:

Single row 5x5 dot matrix, 366m/min (1200 ft / min)

Single row 7x5 dot matrix, 276m /min(905ft / min)

Double rows 7x5 dot matrix, 100m / min (328ft / min)

Three rows 7x5 dot matrix, 58 m / min (190 ft / min)

Barcode Types:

Code39, Code128, EAN128, EAN-8, EAN-13,

UPC-A&E,QR code, DataMatrix

Font Matrix:

1 row:5X5、7x5, 9x7, 11x7, 15x11,23x15, 32x24

2 rows:5x5, 7x5, 9x7, 11x7, 15x11, 23x15

3 rows:5x5, 7x5, 9x7, 11x7, 15x11

4 rows:5x5, 7x5, 9x7, 11x7

Message Height:

Minimum  1mm~20mm(0.04 ~0.8inc, variable depends on fonts

Distance between head to object:



Input Language & Interface:

English, Chinese, Arabic, Persi, Latin, Russion etc.

One button print start / stop, control print delay, reverse print, invert print, bold print, auto-start self-clean

Ethernet, RS-232, 3 USB ports for communication/wi-fi, alarm, tablet charging

Nozzle Size:

50μm nozzle standard, 40μm nozzle optional


Coms Input-Photocell/trigger, encoder, reverse print, external counter increment

Coms Outputs-Alarm light (3-color), print ready, warning

Main Application Fields:

It provides superior quality small characters on a variety of substrates: porous, non-porous, smooth textured, curved, concave and more.

It offers a reliable ,yet cost effective solution for virtually any small character, primary package coding applications such as plastic bags, paper bags, paper, glass, mental, medicine box, cartons, electronic products, labels, Nylon, ABS/PVC/PE, rubber, resins, ceramics etc.

Print samples:

Cabinet & Head Dimension
